Product Details:
Payment & Shipping Terms:
|
| Name: | Automatic Soda Filling Machine | Weight(kg): | 6000 |
|---|---|---|---|
| Motor Power(kw): | 6.2 | Applicable Bottle: | Pet Bottle |
| Filling Heads: | 32 | Dimension: | 3880*2200*2250(mm ) |
| Capacity: | 10000 | Capping Heads: | 10 |
| Highlight: | automatic soda filling machine,carbonated juice machine |
||
Specification:
| Capacity | 7000-10000BPH |
| Applicable bottle | PET bottle |
| Applicable filling content | carbonated beverage |
| Main motor Power | 6.2KW |
| 350Dimension | 3880*2200*2250mm (change according to bottle size) |
| Weight | 6000kg (change according to bottle size) |
Feature:
1. This kind of complete set of machine combines washing,filling and rotary capping functions in one unit,is a fully automatic and high efficiency liquid packing equipment.
2. PET bottle carbonated beverage filling line is suitable for packing beverage containing gas. Its performance is as following all parts,for instance, filling valve, which directly contact medium are made of stainless steel or harmless material. So it conforms to the requirements of Food sanitation. Sealing parts are made of heat-proofing rubber, in order to meet the technique requirements of users to sterilization at high temperature.
Description:
1. Using programmable controller to realize fully automatic control from bottles entering to finishing packing,
2. Using transducer as speed regulator, so the user can regulate the machine easily to suit different power requirements, Adopting equal pressure filling principle and current spring valves in order to assure beverage quality, Using advanced magnetic coupler to regulate cap-screwing torque, in order to assure capping quality.
Details:
1. Adopt air conveyor system with high efficient filter to feed bottle, this can keep the inside of the filling machine clean
2. With bottle neck holding in the whole course and protect bottle block device.
3. Parameters:
Body material: SUS304
Side guide bracket: reinforced polyamide
Air motor material: metal
Power: 1.1KW
Air flow: 2000m3/h
Air pressure: 1400Pa
Speed: 2480Rpm
