SUS304 Fully Automatic Bottle Filling Machines 1000-30000BPH For Grain Juice

SUS304 Fully Automatic Bottle Filling Machines 1000-30000BPH For Grain Juice

Specifications:

1. material: sus304
2. capacity:1000-30000BPH
3. size: 200ml-2000ml

Feature :

1) Using the wind sent access, with clamp hanging the bottle neck ; which can keep the bottle shape and high-speed.

2 Washing bottle mouth with special designed washing manipulator,clip in the bottle neck, stable and avoid secondary pollution.

3) Grain filling uses measuring cup to quantify, ensure grain uniformity.

4) Capping adopts French advanced technology, cap sorter install in a lower position, send cap in level position.

5) Host adopts advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.

The total pulp juice filling machine uses advanced photoelectric detection technology to detect each part’s operation status, no bottle no filling, and no bottle no capping, automatic and easy operation.

Details:

Type: Filling Machine

Condition: New

Automatic Grade: Automatic

Driven Type: Electric

Voltage: 380V

Power: 5.8KW

Application: Food, Beverage, Commodity

Dimension(L*W*H): 2900*1900*2300(mm)

Weight: 4500kg

Certification: CE ISO

After-sales Service Provided: Engineers available to service machinery overseas

Filling Speed:1000BPH-30000BPH

Filling Volume:200ML-2000ML

Material: SUS 304

Grain Juice Bottling Machine:PLC control
