24 Heads Mango Juice Filling Machine 500ml Bottling Juice Equipment

Large Image : 24 Heads Mango Juice Filling Machine 500ml Bottling Juice Equipment

Product Details:

Place of Origin:	CHINA
Brand Name:	OEM
Certification:	RoHS,CE

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	standard Package
Delivery Time:	10-30 days
Payment Terms:	T/T, L/C, T/T, Western Union
Supply Ability:	10 sets/month

Contact Now

Detailed Product Description

Name:	Orange Juice Production Line	Capping Heads:	8
Bottle Size:	500ml	Filling Heads:	24
Rinsing Heads:	24	Material:	SUS304
Highlight:	fruit juice processing equipment , glass bottle filling machine

High Speed Mango Juice Filling Machine 500ml Bottling Juice Equipment

Feature:

1) Adopting clamping bottleneck way to wash bottle mouth and avoid touching screw muth,adopting clamping bottleneck way in the whole conveying process.When bottle

type changes,you need to change the board related with bottle diameter .

2) Bottle is entered by air conveyor,the speed of bottle entering is fast and bottle shape isn’t changed because of adopting hanging clamping bottleneck way.

Description:

1. fruit juice filling machine 3 in 1 is possible to realize manmachine conversation because of applying touch screen for operation

2. This grain juice bottling machine has washing ,grain filling,juice filling ,capping four functions in one body.

3. Grain filling is quantitative by new measuring cup; ensure every bottle of drink is uniformity.

Specification:

Model	RCGF16126	RCGF18186	RCGF24248	RCGF323210
Heads of washing,filling,sealing	16-12-6	18-18-6	24-24-8	32-32-10
Production capacity	3000-4000BPH	5000-7000	8000-12000	12000-15000
Suitable bottle diameter	φ=50-100mm, H=170mm, 330-2500ml	φ=50-100mm, H=170mm, 330-2500ml	φ=50-100mm, H=170mm, 330-2500ml	φ=50-100mm, H=170mm, 330-2500ml
Spraying pressure	0.2-0.25Mpa	0.2-0.25Mpa	0.2-0.25Mpa ³	0.2-0.25Mpa
Motor power	2.2kw	2.5kw	3kw	5.5kw
Stainless steel	SS304	SS304	SS304	SS304
Electric voltage	380V50Hz	380V50Hz	380V50Hz	380V50Hz
PLC	Mitsubishi	Mitsubishi	Mitsubishi	Mitsubishi
Frequency converters	Mitsubishi	Mitsubishi	Mitsubishi	Mitsubishi
Touch screen	Mitsubishi	Mitsubishi	Mitsubishi	Mitsubishi
Circuit contactor	Siemens	Siemens	Siemens	Siemens
overall dimension	240016002500	250018002500	310023002800	380028002900
Weight	2500kg	3500kg	4500kg	6500kg

Details:

1) The PLC and transducer are chosen from international famous brand,such as OMRON,MITSUBISHI and so on.

2) Filling adopts cylinder feeding structure,filling vale adopts high filling speed and mass flow rate valve which control liquids level accurately and without loss.

3) The capping system applies advanced French technology,when clamp the cap will screw immediately and magnetic torque type capping head.
